Specification

Power	1 to 50 HP
Speed	2900 rpm
Version	3Ph 380V, 50Hz
Duty	S1 (Continuous)
Protection	IP 68
Insulation Class	F
Head Range	2 to 65 m
Flow Range	65 to 7650 lpm

Pump Casing	SS 202
Motor Housing	SS 202
Impeller	Cast Iron
Shaft	SS 410
Seal	Tungsten Carbide vs Tungsten Carbide

Max. Liquid Temp.	50°C

Building & Construction site
Mining
Power & Steel Plant
Flood

Performance Table

Model	HP	kW	Outlet Size (mm)	Solid Size (mm)		2	4	6	8	10	14	18	24	28
Model	HP	kW	Outlet Size (mm)	Solid Size (mm)		BloRaD I-10DT	1	0.75	50	12	Discharge in lpm	400	352	304	240	144
BloRaD I-15DT	1.5	1.1	50	15	800	660	460	160
BloRaD II-15DT	1.5	1.1	50	12	470	430	385	335	270	70
BloRaD I-20DT	2	1.5	50	15	900	800	625	440
BloRaD II-20DT	2	1.5	50	15	550	525	485	437	380	225
BloRaD I-30DT	3	2.2	50	12		400	385	370	360	325		275	175	65
BloRaD I-30FT	3	2.2	75	15		880	800	700	600	370		120
BloRaD I-50DT	5	3.7	50	12		750	720	690	650	580		480	270	105
BloRaD I-50FT	5	3.7	75	15		1100	1070	1050	1000	820		590
BloRaD I-75FT	7.5	5.5	75	15		1375	1305	1250	1180	1045		875	500	170
BloRaD I-100FT	10	7.5	75	15		2400	2300	2200	2100	1875		1575	1000	500

Model	HP	kW	Outlet Size (mm)	Solid Size (mm)		4	8	12	16	20	24	28	32	36	40	45	50	55	60	65
Model	HP	kW	Outlet Size (mm)	Solid Size (mm)		BloRaD-50GT	5	3.7	100	20	Discharge in lpm	2200	1760	920												65
BloRaD-75GT	7.5	5.5	100	20	2400	2100	1400
BloRaD-100GT	10	7.5	100	20	2400	2200	2000	1750	1400	1000		500
BloRaD-125GT	12.5	9.3	100	20	2500	2350	2150	1950	1700	1400		1000	550
BloRaD-150GT	15	11	100	20	2800	2600	2400	2175	1950	1700		1400	1100	750	350
BloRaD-200GT	20	15	100	20		2640	2550	2400	2220	2040		1860	1620	1380	1080	660	180
BloRaD-100IT	10	7.5	150	30	3900	3200	2000
BloRaD-125IT	12.5	9.3	150	30	4500	3850	2800	1250
BloRaD-150IT	15	11	150	30	4500	3950	3350	2600	1800	950
BloRaD-200IT	20	15	150	30	5000	4500	4000	3400	2750	2000		1200	400
BloRaD-250IT	25	18.5	150	25			3800	3500	3150	2800		2400	2000	1600	1100	450
BloRaD-300IT	30	22	150	25			4000	3800	3500	3200		2800	2500	2100	1700	1100	500
BloRaD-350IT	35	26	150	25			4400	4200	3900	3650		3300	3000	2600	2200	1650	1050	550
BloRaD-400IT	40	30	150	35	7250	6050	6080	5350	4550	3190		2395
BloRaD-500IT	50	37	150	35	8150	7875	6950	6200	5650	4850		4100	3387	2134	1334
BloRaD II-400IT	40	30	150	30	4350	4080	3890	3710	3550	3370		3120	2880	2580	2300	1850	1350	600
BloRaD II-500IT	50	37	150	30			4400	4220	4100	3990		3690	3505	3290	3050	2350	2350	1890	1400	700

Model	HP	kW	Outlet Size (mm)	Solid Size (mm)	Discharge in lpm
Model	HP	kW	Outlet Size (mm)	Solid Size (mm)	6	8	10	12	14	16	18	20	24
BoIRaD-250IT	25	18.5	200	35	6750	6300	5925	5300	4500	3750	2550	1500
BoIRaD-300IT	30	22	200	35		7125	6750	6300	5700	5150	4125	3000	675
BoIRaD-350IT	35	26	200	35		7650	6900	6525	6525	6000	5400	4725	3000
